Description
GolPumps’ Encapsulated-resin-filled motor is developed with the market expectation to meet the robust construction and stringent requirement, which is for a 4” or larger well. The motor is 100% tested before shipment.
Pump Spec
- Max Head(ft): 170
- Max Flow(Gpm): 47
- Discharge: 2″
- HP: 1
- Pump Material: Noryl
- Pump Model: ST 3506
Product Advantages
- Hermetically sealed stator, anti-track, stator resin filled prevent motor burn out.
- High efficiency provides operation cost savings Thrust pad.
- Copper wiring.
- Pressure equalizing diaphragm.
- Removable lead connector.
- Control boxes are available for single-phase motor Standard NEMA mounting dimensions.
Technical Specifications
- Upper bracket: Cataphoresis-treated cast iron plus SS304 cover cap.
- Max. Immersion depth: 985 ft.
- Protection: IP68.
- Nos. of start per hour: max 20 at regular intervals.
- Sand slinger and lip seal.
- Insulation: Class F.
- Rated ambient temperature: 86°F with min.
- Cooling flow 0.08 m/s of water flow speed.
- Standard installation position: vertical and horizontal.
Model Pump ST 35-6 Motor 4CF3526M Brand Gol Pumps Manufacturer’s Warranty 1-year Limited Warranty P2 kW 0.75 HP 1 Service Factor 1.4 Material Pump Noryl Motor Noryl Voltage – Phase 230V – Single Phase Wire 2 In A 5.4 Imax A 6.8 Istart A 24.2 PF (%) Allowable Load 0.97 Overload Factor 0.98 Efficiency (%) Allowable Load 62.7 Overload Factor 68.2 R.P.M 3450 Thrust N 3000 Capacitor UF 25UF 450V Cable AWG 14 Length (ft.) 3.9 Production Country Taiwan Dimensions and Weights
Outlet Motor Dia. Dimensions (inch) Weight (lb) A B C D Pump Motor Pump + Motor NPT 2″ 4″ 14.1″ 2″ 3.9″ 29″ 7.5 25.3 32.8
