Description
Description
- Fitted with an overhung impeller directly splined key-way on to the motor shaft
- Cast iron body and motor support for rugged durability
- Pressed brass impeller resists corrosion
- Carbon/ceramic mechanical seal or wear resistance and long life
- Totally enclosed fan-cooled motor
- 5°F–158°F temperature range
- 75.4 PSI max. working pressure
MADE IN ITALY
Download Catalog: SpringPump-SAER-Products.pdf
1 Year Warranty |
More Details:
Model | CM1B |
Brand | Saer-USA |
Manufacturer’s Warranty | 1-year Limited Warranty |
Ship Weight | 55.0 lbs |
Port Size (in.) | 1 |
Flow (GPH) | 2106 |
HP | 2.2 |
Volts | 230 |
Amps | 13 |
Max. Total Head (ft.) | 167 |
Max. Suction Lift (ft.) | 17 |
Max. PSI | 75.4 |
Suction Port (in.) | 1 |
Discharge Port (in.) | 1 |
Self-Priming | No |
Dimensions L x W x H (in.) | 14.9 x 9.5 x 11.5 |
Product Weight (lbs.) | 55 |
